    Tw - 40 Metal Filter Cartridge Round Mesh Strainer For Dielectric Filtration

    Ask Lasest Price
    Brand Name : Air
    Model Number : AR-PF
    Price : negotiation
    Payment Terms : T/T(negotiation)
    Supply Ability : around 30000 pcs per year
    Delivery Time : around 2weeks upon receipt&stamped PO
    • Product Details
    • Company Profile

    Tw - 40 Metal Filter Cartridge Round Mesh Strainer For Dielectric Filtration

    Wire Cut EDM Machine Filter for MAXI MITSUBISHI Charmilles Wire Cut Parts for Filter TW-31
    description

    Packaging & Delivery

    Packaging Details
    1 set in a box, 2 boxes to a carton
    Delivery Time
    within 5 days

    Specifications

    TW-40 used cnc edm wire cutting machine Filter
    Brand Name: Fongbin
    Model Number: TW-40

    TW-40 wire cut edm filter for Mitsubishi Filter

    Packaging & Delivery

    Packaging Details:1unit/box, 2units/carton Neutral packing or Brand decal as customers request
    Delivery Detail:10-15days

    Specifications

    mitsubishi wire cut edm filter

    King filter Model:TW-40 with side nozzle Dimensions(OD*ID*Hmm ):300*59*500 Used for: MISUBISHI SEIBU MAKINO HITACHI TAIWAN

    round mesh strainer
    Model:TW-40 with side nozzle

    1, applications
    For the filtration of dielectric medium in wire erosion and sink erosion machines

    2, Dimension

    Outer diameterInner diameterHeight
    300mm59mm500mm


    3, feature

    Flower directionFilter finenessFilter surface areaExpected service filter
    IN/EX5 μm14 m3480-720 hours


    4, Filterpaper
    Filterpaper imported from South Korea

    5, Pressure
    Max operation pressure: 1.98 Bar and Resistance to pressure: 2.94 Bar

    6, Packing
    1unit/box, 2units/carton

    7, Weight
    net weight:6.3KG goss weight:8.0KG

    8, Volume
    the size of carton: 0.70m*0.35m*0.60m

    9, Used for: MISUBISHI SEIBU MAKINO HITACHI TAIWAN

    MITSUBISHI------DWC(90B,90SB,90Z,90SZ,90SZP,110Z,110SZ,110SZ-P) DWC(110A,110SA,110PA) TAiWAN QIINGHONG YATE
    SEIBU------A Series EW-(A5,A5S,A7S) EW-C3,EWP-B3S K2 Series EW-(300,450,600,700,1000)K238
    HITACH------H-CUT203M,203Q,205QSeries H-CUT(3Q,4Q,5Q,6Q,8Q) H-CUT 3HP
    MAKINO------EE3,EE6,EE6L,EH3,6,EQ5,EQH5,EQF5,MU43,MUQ32,EC32,EC64,ECQ53
    TAIWAN------TAIWAN CHMER ARD JIANSHNE LAITONGAN

    Wire Cut EDM Machine Filter for MAXI MITSUBISHI Charmilles Wire Cut Parts for Filter TW-31

    Materialpaper, steel, copper/bronze
    specifications300*58/59*500mm
    Compatible


    MITSUBISHI: DWC(90B, 90SB, 90Z, 90SZ, 90SZP, 110Z, 110SZ, 110SZ-P)
    DWC(110A, 110SA, 110PA)
    MAKONO: EE3, EE6, EE6L, EQ5, EQH5, EQF5, MU43, MUQ32, EC32, EC64, ECQ53
    TAIWAN SERIES: CJINGHUANG, ARD
    HITACHI: H-CUT203M, 203Q, 205Q SERIES
    H-CUT(3Q, 4Q, 5Q, 6Q, 8Q)
    H-CUT3HP
    SEIBU: A SRIES EW-(A5, A5S, A7S)
    EW-C3, EWP-B3S
    K2 SERIES EW-(300, 450, 600, 700, 1000)
    K238

    Packing detail:

    1.Cardboard, two pecies for one carton
    2.Carton size and weight: : according to the cargoes

    Lead time7-15 days, up to the quantity and distance.


    MOQ:

    1. MOQ :100PCS.
    2. First time no MOQ request, trial order and mix order accepted.
    3. Larger quantity please contact sales for discount.
    Quality control100% second check by QC to be sure all in good conditions.
    WarrantyIf there is any brokage (not made by human) when the cargoes achieved the destination, we make sure to exchange according the picture show.
    Payment:T/T, down payment 30%, pay the balance of 70% on the notification before shipping
    Shipment:Shipping by FOB generally, CIF,C&F available.
    SampleAvailable, free for large amount.
    OEM&ODM:We accept OEM & ODM, welcome sending us your artwork, sample, picture
