    Steel plate pre-processing container plants smelters foundries Shot Blasting Machines Filter Cartridges

    Ask Lasest Price
    Brand Name : AIER
    Price : Negotiation
    Payment Terms : T/T(Negotiation)
    Supply Ability : around 30000pcs per year
    Delivery Time : around 2 weeks upon receipt signed&stamped PO
    • Product Details
    • Company Profile

    Steel plate pre-processing container plants smelters foundries Shot Blasting Machines Filter Cartridges

    Steel plate pre-processing container plants smelters foundries Shot Blasting Machines Filter Cartridges Description​:


    Performance:

    1) Unique plastic coating anti-rust caps and metal frame
    2) Wide pleat spacing,easy-cleaning design
    3) Unique plastic rotation,effectively separate the pleats,protect the filter media from abrasion by inner mesh;
    4)Top open, bottom open/bottom close with deflating bolt hole;

    5) A variety of installation methods;
    6) Optional outer mesh;
    7)Optional temperature at 130 °C;
    8)Optional stainless steel mesh and end caps.


    Specification:

    Product CodeSize (mm)Filtration area(m2)
    AR3566φ352*φ241*6609.4
    AR3266φ324*φ213*660

    9.4


    Dust filter cartridge Materials:

    CodeWeightThicknessFilter PrecisionContinuous TemperaturePeaks Temperature
    (g/m²)(mm)(µm)

    Polyester

    2400.65(μm)65 (°C)130 (°C)
    2600.64

    Water & oil repllent

    2400.65(μm)65 (°C)130 (°C)
    2600.64

    Antistatic coating

    2400.65(μm)65 (°C)110 (°C)
    2600.64
    2400.6

    PTFE membrane

    2400.60.5(μm)65 (°C)130 (°C)
    2600.64

    Advantages:

    1) The most professional manufacturer of filter cartridge apparatus in China;
    2) One of the suppliers that has passed Andrew certification in China;
    3) The quality of our PU material is the same as international brand products.


    Applications:

    Mainly used in steel plate pre-processing for large-scale shipyards, container plants, smelters, foundries, large steel, locomotives, etc.


    Details:

    Height: Customized as per your request, usually it is 600mm, 1200mm
    Top Cap: Electro galvanized
    Bottom Cap: Electro galvanized
    Inner Liner/Mesh: Galvanized
    Outer Retainer: Outer Strap
    Filter Media Option:

    PTFE Membrane Polyester / Antistatic / Oil, water repellent / Polyester FR/ OR 80%cellulose+20%polyester / Nanoweb / 80%cellulose+20%polyester with Antistatic
    Gasket: EPDM
    Glue: Epoxy Resin
