    5um,0.5um,2um,0.2um325 * 660 Non - Woven Dust Filter Cartridge With Square End Cap Easy To Install

    Ask Lasest Price
    Brand Name : Air
    Model Number : AR-PE3266
    Price : Negotiation
    Payment Terms : T/T(Negotiation)
    Supply Ability : around 30000pcs per year
    Delivery Time : around 2 weeks upon receipt signed&stamped PO
    • Product Details
    • Company Profile

    5um,0.5um,2um,0.2um325 * 660 Non - Woven Dust Filter Cartridge With Square End Cap Easy To Install

    Square End Cap Dust Replacement Air Filter Dust Filter 325 * 660 Polyester Fiber / Non-Woven / Dust Filter Cartridge​ ​Descriptions:

    Performance Description

    • Wider pleat width
    • High filter efficiency
    • Suitable design for easy to self-clean
    • Top open, bottom open/ bottom close with deflating bolt hole
    • Galvanized stainless metal configuration
    • Rubber seal
    • Various ways of flange installation
    • Superior ability of pressive strength
    • Good abrasion resistance and other after-treatment of filter material
    • Washable filter media, can be used many times

    Square End Cap Dust Replacement Air Filter

    Product Description
    Cartridge ModelTop Cap OD mmTop Cap ID mmBottom Cap OD mmBolt Hole mmHeight mmFiltration Surface m2
    3266
    (Square Cover)
    406*362*Φ324φ213Φ324/6609.4
    3266
    (Square Cover)
    406*362*Φ324φ213Φ324/6609.4
    3266
    (Square Cover)
    406*362*Φ324φ213Φ324/66021

    Dust filter cartridge

    Product features:

    Top capGalvanized steel / stainless steel
    GasketEPDM / Silicone
    Inner meshGalvanized steel
    Outer meshNone / galvanized steel
    Closed bottom capGalvanized steel
    Filter mediaPolyester / cellulose
    Installation ,methodSide-install, chuck type
    Wide pleated design , high filtration efficiency

    Filter is a certain length of the filter material folded into a fold, the first end of the star-shaped filter cartridge. Filter cage without cage, easy to install.

    There are many varieties of filter, with thin and long and thick and short points. (Such as φ ≤ 160, L = 1 ~ 2m), the pleats (such as 45 fold) between the large gap, the angle is large, shallow and shallow folds, filter area than the same diameter filter bag 2 ~ 5 times, easy to clean and effective; for concentration ≥ 15g / m dust filter dust, filter wind speed 0.6 ~ 1.2m / min. (Such as φ350, L = 0.66m) large diameter, short length, pleats more (120 ~ 350 fold) and deep, small gap between the gap, large filter area, compared with the same diameter with the same filter bag area 14 ~ 35 times, suitable for small site area, small space layout.


    Filter cartridge dust collector installed in three ways: vertical, tilt, horizontal installation. Cartridge vertical installation, pulse cleaning, the dust is easy to settle down to the ash bucket, the effect is good. Tilt installation, the cartridge up and down the stack, compact structure, small footprint, easy to change the tube, but the cleaning, the upper filter dust off the dust on the lower filter, it is difficult to clear. Horizontal installation, the lower part of the filter cartridge dust is more difficult to remove. Tilt installation filter cartridge for small and medium dust removal system non-sticky, low concentration, coarse dust dust, but also for some old bags of dust with the transformation.

    Application:
    Electronic,rubber,battery and others
    Can replace relevant products of FARR,TENKAY,GE,NORDIC

    Dust filter cartridge

    Square End Cap Dust Replacement Air Filter Dust Filter 325 * 660 Polyester Fiber / Non-Woven / Dust Filter Cartridge​ Details Show:


    https://youtu.be/IV795B_37vU

    https://www.youtube.com/watch?v=h7xUgYrQosA
